razor barbed wire


Anping County Baodi Metal Mesh Co.,Ltd. supplies razor barbed wire products which can be used together or separately to provide security to facilities and houses.
Forms of corrosion resistance include electric galvanizing, hot-dipp galvanizing.




Razor Blade Specification:


Reference Number

Blade Style

Thickness

Wire Dia

Barb
Length

Barb
Width

Barb
spacing

BTO-10

0.5±0.05

2.5±0.1

10±1

13±1

26±1

BTO-15

0.5±0.05

2.5±0.1

15±1

15±1

33±1

BTO-22

0.5±0.05

2.5±0.1

22±1

15±1

34±1

CBT-65

0.6±0.05

2.5±0.1

65±2

21±1

100±2



Technical Info of PVC Coated Barbed Iron Wire:

  • Core of PVC Coated Barbed Iron Wire can be galvanized iron wire or black annealed iron wire.
  • A variety of colors like green, blue, yellow, orange, gray, is available with PVC Coated Barbed Iron Wire produced by us.
  • Tensile strength of Standard PVC Coated Barbed Iron Wire is 30-45 kgs./sq.mm.
  • Packing: In coil of 25 kilos or 50 kilos net, lined with P.V.C strips, then wrapped with P.V.C or hessian cloth.

Barbed Tape Wire Specification:



Outside Diameter

No. of Loops

Standard Length per Coil

Type

Notes

450mm

33

8M

CBT-65

Single coil

500mm

41

10M

CBT-65

Single coil

700mm

41

10M

CBT-65

Single coil

960mm

53

13M

CBT-65

Single coil

500mm

102

16M

BTO-10.15.22

Cross type

600mm

86

14M

BTO-10.15.22

Cross type

700mm

72

12M

BTO-10.15.22

Cross type

800mm

64

10M

BTO-10.15.22

Cross type

960mm

52

9M

BTO-10.15.22

Cross type


Notes:
Standard products are shown in the tables above, special specifications available on request.
Standard materials are either galvanized or stainless steel.
